10 SCFM Membrane Compressed Air Dryer, FluidPro 400, Pentair 555731-88-N

Introducing FluidPro series membrane dryers by Pentair – industry leading solutions for high quality compressed air. With a compact design, no moving parts, no electrical power requirement, and no consumables, FluidPro membrane air dryers are an ideal choice in a range of critical applications.

How it works

FluidPro dryers by Pentair use a propriety hollow fiber membrane technology to separate water vapor from compressed air and other process gases. Water vapor permeates the walls of membrane fibers allowing dehydrated air or gas to flow to the dryer outlet. A portion of dry outlet air or gas is used sweep or purge water vapor from the dryer housing. Pressure dew points as low as -40° F can be achieve with FluidPro dryers.

Specifications

• Model FluidPro 400, part number 555731-88-N
• Rating to deliver 37° F pressure dew point: 10 SCFM @ 100 PSIG and 95° F air inlet, 14% purge
• Rating to deliver -4° F pressure dew point: 6.7 SCFM @ 100 PSIG, 21% purge
• Rating to delivery -40° F pressure dew point: 4.8 SCFM @ 100 PSIG, 29% purge
• Max operating pressure: 180 PSIG
• Inlet/Outlet air connections: 1/2″ NPT
• Aluminum shell with nylon end caps
• Overall length: 16.5″
• Width: 3.2″
• Shipping Weight: 3 lb
• Includes coalescing (oil removing) pre-filter with auto drain and .01 micron filter element

Ideal Uses

• Protection of air operated instrumentation at the point-of-use
• Hazardous area locations
• OEM Equipment
• Mobile applications
• Locations with limited or no electrical power

Optional Purge Port Feature

• Available for FluidPro models 300 through 3000
• Allows users toggle purge flow on-off
• Permits use of alternative dry purge gases (e.g. use instrument air for purge when valuable process is being dried).
